continued
					supply to the NAC will not be allowed to close if a short circuit condition
					share a common external supply. Otherwise, each module operates
					currently exists on the NAC. In addition, an algorithm is incorporated to find a independently from the others. The first module is addressed from 01 to 94
					short when the module is active. The module will close all circuits that are not while the remaining modules are assigned to the next five higher addresses.
					shorted to find the NAC with the problem.
					Provisions are included for disabling a maximum of two unused modules.
					All two-wire detectors being monitored must be two-wire compatibility
					listed with the modules. The CZ-6 transmits the status of a zone of two-wire
					detectors to the fire alarm control panel. Status conditions are reported as
					normal, open or alarm. The interface module supervises the zone of detectors
					and the connection of the external power supply.
					SYNC-1 ACCESSORY CARD
					The SYNC-1 is an optional accessory to the SC-6 and is designed to provide
					aꢀmeansꢀofꢀsynchronizingꢀaꢀseriesꢀofꢀhorns,ꢀstrobes,ꢀandꢀhorn/strobes.ꢀTheꢀ
					SYNC-1 is able to synchronize the temporal-coded horns, the one second
					flashꢀtimingꢀofꢀtheꢀstrobe,ꢀandꢀsilencingꢀtheꢀhornsꢀofꢀtheꢀhorn/strobeꢀ
					combination over a two-wire circuit while leaving the strobes active. Each
					SYNC-1 accessory card has the capability of synchronizing six Class B circuits
					or three Class A circuits.
					IM-10 TEN INPUT MONITOR MODULE
					The IM-10 Ten Input Monitor module provides an interface between a
					control panel and normally open contact devices such as pull stations,
					security contacts, or flow switches. The first address is set from 01 to 90 and
					the remaining modules are automatically assigned to the next nine higher
					addresses. Provisions are included for disabling a maximum of two unused
					addresses. The supervised state (normal, open or short) of the monitored
					device is sent back to the panel.
					CZ-6 SIX ZONE INTERFACE MODULE
					The CZ-6 Six Zone Interface module provides an interface between the
					intelligent alarm system and a two-wire conventional detection zone. A
					common SLC input is used for all modules, and the initiating device circuits
					500 Series Module Specifications
					General Specifications
					Specifications: IM-10
					Operating Voltage
					15 to 32 VDC
					Standby Current
					Alarm Current
					3.5 mA maximum
					Maximum SLC Wiring Resistance 40 Ohms
					60 mA maximum (assumes all ten LEDs
					solid on)
					Temperature Range
					Relative Humidity
					Wire Gauge
					32°F to 120°F (0° to 49°C)
					Maximum IDC Wiring Resistance 40 Ohms
					10% to 85% noncondensing
					12 to 18 AWG
					Maximum IDC Voltage
					Maximum IDC Current
					12 VDC
					1 mA
					Dimensions
					6.8˝H × 5.8˝W × 1.25˝D
					Specifications: CR-6
					Standby Current
					Alarm Current
					Accessories
					1.45 mA maximum
					32 mA maximum (assumes all six relays
					have been switched once and all six
					LEDs solid on)
					Maximum IDC Wiring Resistance 40 Ohms
					Relay Current
					30ꢀmA/RelayꢀPulseꢀ(15.6ꢀmSꢀpulseꢀ
					duration) pulse under panel control
					SYNC-1 Accessory Card
					Relay Contact Ratings
					Specifications: CZ-6
					Standby Current
					30ꢀVDC;ꢀ70.7ꢀVAC
					2 mA maximum
					Alarm Current
					40 mA maximum (assumes all six LEDs
					solid on)
					Maximum IDC Wiring Resistance 25 Ohms
					External Supply Voltage
					DC Voltage: 18 to 28 volts power
					limited
					BB-6 Enclosure with CH-6 Chassis
					Ripple Voltage: 0.1 volts RMS maximum
					Current: 90 mA per circuit
					Specifications: SYNC-1
					Operating Voltage
					Compatible Detectors
					Specifications: SC-6
					Standby Current
					Contact System Sensor for a current list
					11 to 30 VDC
					Maximum Load on a Loop
					ClassꢀA/StyleꢀZ:ꢀ3A
					ClassꢀA/StyleꢀY:ꢀ3Aꢀperꢀpair
					2.25 mA maximum
					Standby Current
					+0 Position: 15 mA
					+2 or +4 Position if connected to
					supply: 2.5 mA
					Alarm Current
					35 mA maximum (assumes all six relays
					have been switched once and all six
					LEDs solid on)
					Specifications: BB-2 Enclosure
					Dimensions
					Maximum NAC Circuit Wiring
					Resistance
					40 Ohms
					12˝Hꢀ×ꢀ9˝Wꢀ×ꢀ3.67˝D
					Power Rating Per Circuit
					Relay Contact Ratings
					63ꢀWꢀ@ꢀ70.7ꢀVAC
					Specifications: BB-6 Enclosure
					Dimensions
					30 VDC; 110 VAC
					24˝Hꢀ×ꢀ12.55˝Wꢀ×ꢀ6.47˝D
					©2008 System Sensor.
					3825ꢀOhioꢀAvenueꢀ•ꢀSt.ꢀCharles,ꢀILꢀ60174
					Phone:ꢀ800-SENSOR2ꢀ•ꢀFax:ꢀ630-377-6495
					Product specifications subject to change without notice. Visit systemsensor.com for
					current product information, including the latest version of this data sheet.
					A05-0344-003ꢀ•ꢀ1/09ꢀ•ꢀ#2088
