CZP
multilayer power ferrite bead
EU
features
• Designed to reduce noise at high frequencies
• Standard EIA packages: 1J, 2A, 2B
• Nickel barrier with solder overcoat for excellent
solderability
• Magnetically shielded
• Marking: Black body color with no marking
• Products with lead-free terminations meet
EU RoHS requirements
dimensions and construction
Type
(Inch Size Code)
Dimensions inches (mm)
W
L
W
t
d
1J
.063±.006
.031±.006
.031±.006
.014±.006
L
Solder
(0603)
(1.6 0.15)
(0.8 0.15)
(0.8 0.15)
(0.36 0.15)
Plating
2A
(0805)
.079±.008
(2.0 0.2)
.047±.008
(1.20 0.2)
.035±.008
(0.9 0.2)
.02±.012
(0.51 0.30)
Ni
Plating
2B
(1206)
.126±.008
(3.2 0.2)
.063±.008
(1.6 0.2)
.043±.008
(1.1 0.2)
.02±.012
(0.51 0.30)
Silver
Metallization
t
d
Terminations
(Metallization
Bands)
d
Electrodes
ordering information
New Part #
CZP
2A
F
T
TD
500
P
Permeability
Code
Termination
Material
Type
Size
Packaging
Impedance
Tolerance
2 significant
figures + 1
multiplier
1J
2A
2B
F
P
T: Sn
TD: 7" paper tape
(1J, 2A - 4,000 pieces/reel)
P: ±25%
TE: 7" embossed plastic
(2B - 3,000 pieces/reel)
For further information
on packaging, please refer
to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
2/24/08
233
