FEATURES
PETERMANN
TECHNIK
Time & Frequency Components
- HIGH RELIABILITY FOR LOW COST
- SMALL DIMENSIONS
- EXCELLENT CLOCK SIGNAL GENERATUR FOR 1 Hz TIMING FREQUENCY
SERIES
JYR
PACKAGE
SEE OUTLINE DRAWINGS
JYR26
CRYSTAL HOLDERS
FREQUENCY
JYR38
JYR15
32.768 kHz
35 kΩ MAX.
35 kΩ MAX.
40 kΩ MAX.
MAXIMUM SERIES RESISTANCE
FREQUENCY TOLERANCE AT 25°C
TEMPERATURE RANGE
STORAGE TEMPERATURE
TEMPERATURE STABILITY
LOAD CAPACITANCE
DRIVE LEVEL
+-20 PPM STANDARD (+-10 ~ +-50 PPM POSSIBLE)
-10/+60°C
-20/+70°C
-0.035 PPM/°C² TYP.
12.5 PF STANDARD
1.6 PF TYP.
1.35 PF TYP.
1.0 PF TYP.
1 µW TYP.
+-3 PPM PER YEAR
BULKS
AGING
DELIVERY FORM
OTHER PARAMETERS ARE AVAILABLE ON REQUEST / CREATE HERE YOUR SPECIFICATION
PART NUMBERING SYSTEM
EXAMPLE
JYR38 32.768 kHz +-20 PPM 12.5 PF
JYR38 OR JYR26 OR JYR15
SERIES
FREQUENCY
32.768 kHz
FREQUENCY TOLERANCE AT 25°C REQUIRED VALUE
LOAD CAPACITANCE
REQUIRED VALUE
OUTLINE DRAWING JYR 26
3.0
2.0
1.32
0.3
0.2
0.2
0.45
0.6
1.1
Unit:mm
Unit:mm
Unit:mm
TEMPERATURE CHARACTERISTICS
-10
25
60
TEMP
(°C)
0
-50
f/f0(ppm)
