Monocolor Flexible SMD LED Strip Specification
PartNO.:
3528UGC-60-12V
FYSH-
●
How to use:
1. Please use this product with 12V DC.
2. Please complete the ESD-prevention before using.
3. The flexible LED strips should be neither bent into right-angles nor folded.
4. For this product, every three LEDs on the same strip can be cut off and use separately
(namely, every 100mm works as a group). Please refer to the ‘Outline’ for the details.
5. The calculating way that how many this product a power supply can upload is: the current(A)
that
the power supply can offer/the current distributed to each single group*total group
of this product
6. The strip quantity of each sting that directly connected to the power supply should not
exceed 30
PCS; otherwise, the brightness of the strip at the end of the string will be dimmed because
of the voltage reduction. Although a loop circuit can avoid reduction happening, one
string should not connect too many strips.
7. The wire with gray line is anode, while the red、green、blue 、yellow、white is cathode, If
polarities
connected in a wrong way, the strip will not be lit, but will not be damaged either. What
only needs to do is changing the polarity connection.
8. When installing the strips in the plastic letters or characters, please try to use 3 or 4
branch wires and when doing the connection try to make the strips in a letter or
character or box form a loop circuit or several loop circuits by using red and black wire to
connect the strips at the end of the strokes together according to their polarities.
9. This product is water-proof.
10.When installing the strip, the double-sided adhesive tape or carpenter’s glue is required
to make the clip slot of the strip firmly stuck together. When using the double-sided
adhesive tape, proper glass glue must be spread to avoid the strip falling off after
long-time exposed in the sunlight.
11.The strip quantity of each sting that directly connected to the power supply should not
exceed
30pcs; otherwise, the brightness of the strip at the end of the string will be dimmed
because of the voltage reduction. Although a loop circuit can avoid reduction happening,
one string should not connect too many strips.
12.No push, squeeze or press on the components of the strip for fear damaging the
affect the lighting effects.
components to
